Buy AMD EPYC 7513 32-Core Server CPU 2.6GHz SP3 Socket 200W TDP Balanced Milan Processor

AMD EPYC 7513 Processor - Full Specifications

Core Architecture & Configuration

• Model: AMD EPYC™ 7513

• Series: EPYC™ 7003 Series ("Milan")

• Core Architecture: AMD "Zen 3"

• Manufacturing Process: 7 nm FinFET

• Number of Cores: 32

• Number of Threads: 64

• Base Clock: 2.60 GHz

• Maximum Boost Clock: Up to 3.65 GHz

• Default TDP / TDP: 200 W

• cTDP: Configurable TDP down: 175 W | Configurable TDP up: 225 W

• Total L3 Cache: 128 MB (Unified, shared across CCDs)

• Total L2 Cache: 32 MB (512 KB per core)

Platform & Interface

• Socket: SP3 (Socket P3) - Compatible with platforms supporting AMD EPYC 7002 (Rome) and 7003 (Milan) series processors.

• A BIOS update is required for existing Rome platforms to support Milan processors.

• PCI Express® Version: PCIe 4.0

• Number of PCIe Lanes: 128 Lanes

• Security: AMD Infinity Guard

• AMD Secure Memory Encryption (SME)

• AMD Secure Encrypted Virtualization (SEV) | SEV-Encrypted State (SEV-ES) | SEV-Secure Nested Paging (SEV-SNP)

Memory Support

• Memory Type: DDR4

• Memory Channels: 8-Channel

• Maximum Memory Speed: Up to 3200 MHz

• ECC Support: Yes, ECC (Error-Correcting Code) memory supported

• Maximum Memory Capacity: 4 TB per socket (with LRDIMMs)

Advanced Features & Technologies

• Supported Technologies:

• AMD Infinity Architecture

• AMD Secure Processor

• AMD Memory Guard

• AMD Virtualization™ (AMD-V™) technology with IOMMU

• AMD-V Extended Migration

• AMD PowerNow!™ technology

• Advanced Platform Management Link (APML)

• Instruction Set Extensions: AMD64, SSE, SSE2, SSE3, SSSE3, SSE4a, SSE4.1, SSE4.2, AVX, AVX2, AVX-512 (BFLOAT16, VNNI), FMA3, AES, CLMUL

Performance & Power

• Launch Date: Q1 2021

• Part Number: 100-100000261

• Thermal Solution: Requires a server-grade active heatsink rated for 200W TDP or higher.

Key Positioning Summary
The AMD EPYC 7513 is a balanced-performance processor within the Milan lineup, optimized for performance-per-watt.

It is engineered for workloads that require:

1. High core and thread density (32C/64T) for virtualization and consolidation.

2. Excellent multi-threaded throughput supported by a large 128MB L3 cache.

3. Energy-efficient operation at 200W TDP, ideal for modern, dense data centers.
