‌Gigabyte MZF2-AC0 Server Motherboard | AMD EPYC™ 9004 | E-ATX | 24 DIMMs | 10GbE LAN & OCP 3.0 NIC

• ‌Form Factor‌: E-ATX (305 × 330 mm)

• ‌Chipset‌: AMD® SoC (System on Chip)

• ‌CPU Support‌: Single AMD EPYC™ 9004 series processor (SP5 socket)

• ‌Memory‌: 12-channel DDR5 RDIMM, 24 × DIMM slots (up to 6TB capacity)

• ‌LAN‌: 2 × 10Gb/s Base-T ports (Broadcom® BCM57416)

• ‌OCP 3.0 NIC‌: 1 × OCP 3.0 slot (optional add-on card)

‌Storage & Expansion‌

• ‌MCIO Connectors‌:

• 2 × MCIO 8i (PCIe Gen5 ×8 or SATA interface)

• 4 × MCIO 8i (PCIe Gen5 ×8 interface)

• ‌M.2 Slot‌: 1 × M.2 (PCIe Gen4 ×4 interface)

• ‌SATA Ports‌: 4 × SATA 6Gbps

• ‌PCIe Slots‌: 4 × PCIe Gen5 ×16 expansion slots (x16/x8/x8/x8 configuration)

‌Management & Security‌

• ‌GIGABYTE Management Console‌: Browser-based GUI for remote monitoring, power control, and BIOS updates.

• ‌TPM Support‌: TPM 2.0 module for hardware security.

‌Power & Cooling‌

• ‌cTDP Support‌: Configurable TDP for optimized power efficiency.

‌I/O Ports‌

• ‌USB‌: Rear panel USB 3.2 Gen2x2 (20Gbps)

• ‌Video‌: 1 × VGA port (for legacy systems)

‌Compliance & Certifications‌

• ‌OS Support‌: Windows Server, Linux distributions (Ubuntu, CentOS, etc.)

• ‌Safety Standards‌: CE, FCC, RoHS compliant.

‌Why Choose MZF2-AC0?‌

• ‌High-density computing‌: Supports up to 192 cores for AI/HPC workloads.

• ‌Future-proof networking‌: OCP 3.0 NIC slot for flexible upgrades.

• ‌Enterprise-grade reliability‌: Designed for 24/7 operation in data centers.

‌Target Audience‌:

• IT professionals deploying enterprise servers.

• Cloud providers scaling virtualization infrastructure.

• Researchers in HPC, AI, and data analytics fields.
